Asus Rog Crosshair X870e Apex AMD X870e Zócalo Am5 Atx
P/N:
90MB1KR0-M0EAY0
Placa base ASUS g Crosshair X870e Apex AMD X870e Zócalo Am5 Atx con compatibilidad Windows 11.
Resumen técnico
Referencia90MB1KR0-M0EAY0
Descripción
Asus Rog Crosshair X870e Apex AMD X870e Zócalo Am5 Atx
ASUS g Crosshair X870e Apex AMD X870e Zócalo Am5 Atx es una placa base que combina compatibilidad Windows 11.
Permite comprobar compatibilidad Windows 11 antes de elegir el producto. Identificación: referencia 90MB1KR0-M0EAY0 y EAN 4711387890240.
Envío y garantía
Envío calculado por destino
MarcaAsustek
Stock5 unidades disponibles
EntregaSegún proveedor, peso y destino
PortesSe calculan al añadir a la cesta
GarantíaOficial del fabricante
Ficha técnica
Características principales
| Sistema operativo Windows soportado | Windows 11 |
|---|---|
| Salida de audio | "ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080*<br />- Impedance sense for front and rear headphone outputs<br />- Supports: Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking<br />- High quality 120 dB SNR stereo playback output and 110 dB SNR recording input<br />- Supports up to 32-Bit/384 kHz playback on front panel"<br /><strong>Audio Features </strong><br />- SupremeFX Shielding Technology <br />- Savitech SV3H712 AMP <br />- Gold-plated audio jacks<br />- Rear optical S/PDIF out port<br />- Premium audio capacitors<br />- Audio cover<br />* A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output. <br />** The LINE OUT port on the rear panel does not support spatial audio. If you wish to use spatial audio, make sure to connect your audio output device to the audio jack on the front panel of your chassis or use a USB interface audio device. |
| Características especiales | <strong>Supports 5 x M.2 slots and 4 x SATA 6 GB/s ports*<br />AMD Ryzen 9000 & 7000 Series Desktop Processors</strong><br />M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)<br />M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)**<br />M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)**<br /><strong>AMD Ryzen 8000 Series Desktop Processors</strong><br />M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)<br />M.2_2 slot (Key M), type 2242/2260/2280 (Not supports)<br />M.2_3 slot (Key M), type 2242/2260/2280 (Not supports)<br /><strong>AMD X870E Chipset</strong><br />DIMM.2_1 slot (Key M), type 2230/2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)<br />DIMM.2_2 slot (Key M), type 2230/2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)<br />4 x SATA 6 GB/s ports<br />* Specifications vary by CPU types.<br />**When M.2_2 is enabled, but M.2_3 is not in use, PCIEX16_1 will run in x8 mode and PCIEX16_2 will be disabled.<br />**When M.2_3 is enabled, but M.2_2 is not in use, PCIEX16_1 will run in x8 mode and PCIEX16_2 will run in x4 mode.<br />**When both M.2_2 and M.2_3 are enabled, PCIEX16_1 will run in x8 mode and PCIEX16_2 will be disabled. |
| Otras características | 2 x DIMM slots, max. 128 GB, DDR5 <br />Supports up to<br />8200+MT/s(OC) with Ryzen 9000 Series Processors,<br />9600+MT/s(OC) with Ryzen 8000 Series Processors<br />8000+MT/s(OC) with Ryzen 7000 Series Processors,<br />ECC and Non-ECC, Un-buffered Memory*<br />Dual channel memory architecture <br />Supports AMD Extended Profiles for Overclocking (EXPO)<br />ASUS Enhanced Memory Profile (AEMP)<br />* Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support list under the Support tab of product information site or visit https://www.asus.com/support/download-center/.<br />* Non-ECC, un-buffered DDR5 memory supports On-Die ECC function. |
| Producción gráfica | 2 x USB4<sup>®</sup> (40Gbps) ports support USB Type-C<sup>®</sup> display outputs*<br />Graphics specifications may vary between CPU types. Please refer to AMD CPU specifications.<br />VGA resolution support depends on processors' or graphic cards' resolution.<br />*Supports max. 4K@60Hz as specified in DisplayPort 1.4a |
| Referencia fabricante | 90MB1KR0-M0EAY0 |
| EAN | 4711387890240 |
